顏料紫23-Corimax紫羅蘭色RLS

Pigment violet 23 is an organic compound that is a commercial pigment. It is member of the dioxazine family of heterocyclic compounds, but derived from carbazoles. It is prepared by condensation of chloranil and 3-amino-N-ethylcarbazole. It has a centrosymmetric angular structure. For many years, the structure was assigned, incorrectly, as having a "linear structure" (EC no. 228-767-9, CAS RN 6358-30-1) which differ in terms of the carbazole ring fusion.

Pigment violet 23 is prepared by condensation of an aniline with chloranil.[From Wiki]

顏料紫23的技術參數

顏色索引號顏料紫23
產品名稱Corimax紫羅蘭色RLS
產品分類有機顏料
耐光性(塗料)7
耐熱性(塗層)200
耐光性(塑料)7
耐熱性(塑料)250
顏色
顏料紫23色
色相分佈

Zeyachem is a global supplier of Dioxazine Violet pigments that provide a bluish violet shade, a color not obtainable by other pigments.

The extremely high color strength of Pigment violet 23 makes it a suitable pigment as a shading component. PV23 also exhibits excellent heat fastness and light fastness properties, making it suitable for inks and many paints and coatings applications.

Corimax Violet RLS is a reddish blue shade Dioxazine Violet (PV23) pigment with very high color strength and excellent overall fastness properties, suitable for inks, paints and coatings, including industrial coatings, powder coatings and automotive coatings.

特徵:

low viscosity, high gloss, high color strength. Pigment Violet 23 is a transparent purple violet pigment with high saturation and tinting strength.

C.I.Pigment Violet 23 show good tinting strength in flexible PVC while poor resistance to immigration.

P.V.23 heat resistance above 230℃ in polyolefins, when used in transparent PS, temperature shall below 220℃, above this PV 23 shall decompose. When worked in polyester, it is 280℃ stable in 5 hours, while concentration shall above 0.05%.

The pigment is easy to use and requires no rinsing. To ensure maximum color intensity and proper adhesion to the pulp, a retention agent must be added to the pulp before the pigment is applied. Our pigments are supplied by volume sizes. The actual weight varies, depending upon the density of the pigment.

應用:

推薦用於汽車塗料,建築塗料,卷材塗料,工業塗料,粉末塗料,印刷漿料,PVC,橡膠,PS,PP,PE,PU,膠印油墨,水性油墨,溶劑油墨,UV油墨。

Pigment Violet 23 (PV 23) has now been around for more than 55 years. Its beginnings go back to 1928, when a patent was filed for the pigment after researchers at the Hoechst company in Germany first undertook the multistage synthesis based on carbazole, an ingredient of coaltar, and chloranile. Until the end of World War II the pigment was only used to process diamine light blue, a direct dyestuff for cotton.

With the invention of reactive dyes, which considerably simplified the dyeing and printing process for cellulose fibers, this application lost its importance. A new and promising use for PV 23 was quickly found due to the pigment’s ability to produce unique colors.

PV 23 has been used as a pigment since 1953. PV 23 belongs to the group of high-performance polycyclic pigments (HPP’s) that are used whenever the requirements for a colorant are particularly high. These include high light fastness and weather fastness, fastness to solvents, and heat stability. In addition, PV 23 stands out by its high coloring power. Under the electron microscope, the crude violet shows a highly granular crystalline form, whereas the pigment particles are miniscule.
———————————————————————————————————————————————————— ————————————————

相關信息

物理和化學特性:
色相或指示燈:藍紫色
相對密度:1.40-1.60
堆積密度/(lb / gal):11.7-13.3
熔點/℃:430-455
平均粒徑/μm:0.04-0.07
顆粒形狀:立方/棒
比表面積/(m2 / g):45-102
pH值/(10%漿料):6.2

產品用途:顏料紫23主要用於塗料,油墨,橡膠和塑料的著色,也用於合成纖維的著色
有124種顏料的商業配方品牌。咔唑嗪是一種應用廣泛而又不尋常的藍紫色品種,單晶紫RN的比表面積為74m2 / g。它廣泛應用於塗料,油墨印刷,塑料和織物印染等各個領域。著色時具有良好的清漆牢度。可用於風乾漆,汽車漆OEM和烘焙漆,特別是具有CuPc色粉和強色調的乳膠漆。它可用於塑料著色,在聚烯烴中的耐熱性為280℃,並且保色性高(對於1 / 3SD的HDPE,僅需要顏料濃度的0.07%);它也可用於聚酯和PE的著色。

綜合原理: 以咔唑為原料,在相轉化催化劑的存在下於常壓下進行N-乙基化,並進行硝化反應和還原反應以合成2-氨基-N-乙基咔唑。使3,5,6-四氯對醌(氯腈)進行縮合和閉環反應,過濾,用水洗滌,乾燥,得到粗製咔唑紫;最後,通過捏合或捏合得到CI顏料紫23,進行一般的著色處理。

別名:Pigment Violet RL; 51319; C.I. Pigment Violet 23; 8,18-Dichloro-5,15-diethyl-5,15-dihydrodiindolo(3,2-b:3',2'-m)tri- phenodioxazine; CI 51319; Diindolo(3,2-b:3',2'-m-)triphenodioxazine, 8,18-dichloro-5,15-diethyl-5,15-dihydro-; Carbazole Dioxazine Violet; Carbazole Violet; Chromofine Violet RE; Cyanadur Violet; Dioxazine Violet; Dioxazine purple; EB Violet 4B7906; EMC Violet RL 10; Fastogen Super Violet RN; Fastogen Super Violet RN-S; Fastogen Super Violet RTS; Fastogen Super Violet RVS; Helio Fast Violet BN; Heliofast Red Violet EE; Heliogen Violet; Heliogen Violet R Toner; Hostaperm Violet RL; Hostaperm Violet RL Special; Hostaperm Violet RL Special 14-4007; Lake Fast Violet RL; Lake Fast Violet RLB; Lionogen Violet R 6100; Lionogen Violet RL; Lionol Violet HR; Monolite Fast Violet R; PV Fast Violet BL; PV Fast Violet RL-SPE; Paliogen Violet 5890; Paliogen Violet L 5890; Permanent Violet; Permanent Violet R; Sandorin Violet BL; Sanyo Permanent Violet BL-D 422; Sumikacoat Fast Violet RSB; Sumitone Fast Violet RL; Sumitone Fast Violet RL 4R; Sumitone Fast Violet RLS; Symuler Fast Violet BBL; Symuler Fast Violet BBLN; Unisperse Violet B-E; Vynamon Violet 2B; 8,18-Dichloro-5,15-diethyl-5,15-dihydrodiindolo(3,2-b:3',2'-m)triphenodioxazine; Diindolo(3,2-b:3',2'-m)triphenodioxazine, 8,18-dichloro-5,15-diethyl-5,15-dihydro-; 8,18-dichloro-5,15-diethyl-5,15-dihydrocarbazolo[3',2':5,6][1,4]oxazino[2,3-b]indolo[2,3-i] phenoxazine

分子結構:顏料紫23分子結構
